L.K. Machinery India Pvt. Ltd. is one of the leading CNC Machine Manufacturers Suppliers in India. We have been in the market since the year 1979.
We have gained the immense popularity for our quality products and services. The CNC Machine Manufacturers have always been a step ahead and are constantly innovating to stay relevant.
Our team is dedicated to providing the best solutions to our clients with a focus on customer satisfaction.
CNC Machines are computerized machines that make precise cuts in the metal and plastic materials. It is an automated machine that uses computer numerical control to perform repetitive machining tasks.
It can be used to move the cutting tool or workpiece using servo motors to ensure accuracy and repeatability during the machining process.
It is a computer-controlled Machine that uses numerical control to make parts from digital files. This allows for greater accuracy and more efficiency than traditional machining methods.
1. Precision machining: CNC Machines are capable of cutting exact dimensions with accuracy.
2. Milling: The Machine can cut through material in a controlled way, using the cutter head to remove material from the workpiece.
3. Routing: The machine can create complex shapes by routing the edges of a flat workpiece.
4. Turning: Turning is used to create round or square holes in materials like wood or metal.
CNC Machine provide the precision and accuracy in the manufacture of parts.
It also has the ability to produce high volumes of products quickly without human intervention.
High efficiency, rare kinds but massive production is the elementary necessity that every manufacturer wins competition in worldwide markets. The proven quality of MV Series machines are in providing of customers with productivity.
Standard Spindle Motor with 11/15Kw is also worked with servo motors in 3-axes with 2/2/3Kw,and continuingly offers asked power and thrust, while doing heavy cutting. Enlarged the castings of column and head on MV series, in order to allow Y-axis travel up to 600mm; make the applications widely use to ultimate ranges. LK Machinery India Pvt. Ltd
No matter of machinery or assembly parts, or general Machining for molds, MV Series machines can let you have the ultimate efficiency in production, which is definitely an utmost & economic investment.
High Speed and Steady Auto Tool Change System Direct Drive High-Speed Spindle at 10000 rpm. Direct Drive Spindle with 10,000rpm is the standard for MVP Series. Motor and spindle are connected by high precise coupling, and perform excellent transmission, display outstanding cutting.
| Face Milling | Drilling | ||||
|---|---|---|---|---|---|
| Tool | D63-45 F.M. Cutter | D63-45 F.M. Cutter | Tool | D50 Tapper-Shank Drill | D50 Tapper-Shank Drill |
| Spindle | 1500 | 4000 | |||
| Feedrate | 1500 | 6000 | Spindle | 260 | 300 |
| Cutting Depth | 5mm | 4mm | Feedrate | 26 | 60 |
| Cutting Width | 50mm | 60mm | Cutting Depth | 35mm | 35mm |
| Material | S45C | ALC | Material | S45C | AL5083 |
| Chip removal rate | 375C.C. | 1440CC | |||
| End Milling | Tapping | ||||
| Tool | D40 4-blade E.M. Cutter | D40 4-blade E.M. Cutter | Tool | M24 x P3 Tap | M30 X P3.5Tap |
| Spindle | 2000 | 2500 | Spindle | 150 | 200 |
| Feedrate | 1600 | 3000 | |||
| Cutting Depth | 3.0mm | 10.0mm | Feedrate | 450 | 700 |
| Cutting Width | 35mm | 25mm | Cutting Depth | 30mm | 35mm |
| Material | S45C | ALC | Material | S45C | AL5083 |
| Chip removal rate | 168C.C. | 750C.C. |
| MODEL | MVP-1050 MVP-650 MVP-850 | |
|---|---|---|
| CNC Control | Mitsubishi MBO | |
| Spindle Motor | 11/15kw | |
| X/Y/Z Rapid Feedrate | 45/48/36 | |
| Tapping Efficiency MExP1(sechole) | ADC 1.89 | |
| Comparison of Cutting Efficiency | Regular CNC Machine | ProMill |
| Rapid | m/min M | |
| Rapid Travel improved up to 33% | ||
| 22 | ||
| T-T | sec | Time-saving up 40% |
| C-C | sec | Time-saving 30% |
| Spindle | Normal Victor | Acceleration/deceleration is better up to 15% |
makes the possibility of coolant be worse and spoiled much LESS than other normal choices on the markets. The film of oil has better consistency, which can be pretty mitigating the problem of wearing parts/ assembling out. With higher benefit of economics, the general expense per year, including man power, can be decreased one time at least.
Arm type of tool changing system is STANDARD. Hi-speed and constant of tool changing can supply you bestellect & quality of impressive manufacture.
To fit with the requirement of cutting forging mental, the high rapid travel is important; except to have hi-functional & hi-speed spindle, LK Machinery India Pvt. Ltd chooses powerful motors on axes, which can be supplied successively thrust. At the meantime, the MVP series is not only used powerful motors on axes, but also are equipped with pre-loaded ball screws and high-class linear quideway, machines just can be demonstrated qualified cutting presentation
MVD Series is designed for mold manufacturing, which is carried with characteristics of mighty capability and incomparable accuracy: be adopted with Direct Drive Spindle at 12.000rpm (BT-40). By the sketch of BT-40 as option chuck, it can be delivered remarkable performance, which is aimed at various kinds of strong hardness of mold and fixture.
Ball Bar Test Roller screws of 3 axes have in connection with the entire to be inspected by
Laser accuracy of the machine, L.K. Calibration. The backlash Machinery always
performs in every checked pichis
Ball Bar Test to all machines automatically compensated
centers, in order to be certain into CNC and enhancing the the roundness, straightness
maximum positioning as well concentricity, parallelism and As repeably accuracy of the
perpendicularity reaching to the
For the sake of reaching to the maximum production, L.K. Machining Center is assembled with low inertia motor, and it can offer torque at low speed. At the same time, i a ration deceleration output shares the tapping time to the
Shaped Wide-Stance Column The width of the machine column base is largely widened for extra static as well as dynamic rigidity of machine. The 'A' shaped column showcases excellent damping coefficient to deal with heavy duty cutting. The finish of workpiece is boosted and the lifetime of cutting tool is extended Yaris Travel The wide span of X/Y slideways is able to Strengthen the leadiness
Synchronic tapping function at high-speed (OMR-DD) in spindle and servo control is paired with a function of tolerance compensation at high-speed, so superior precision and hi-speed of tapping is able to be achieved. GEO
High-speed Turning Mode:
The process is made by a sequence of slight movement
amounts and also several segments can be read, in this condition, it can be executed the
tuming by 33,000 segments/min . at a high speed. (Corresponding model M80 Type A)
High-accuracy Control Mode:
At the section of corner made by two straight lines, while executing the movement of
finishing round face, it can be done auxiliary control instantly in accordance with the
locus of instruction at the same time decrease the tolerance when the movement of finishing
round face is possible toward inner side. The practical control in locus is more approached
to a value by instruction.
Interpolation Control of 10 Nano:
Even to a commend of turning sequence by unit of one Nano, the interpolation by a unit of 10
Nano can be processed also, hence the more accurate turning is able to be carried out.
MVD series is Adopted with Siemens 828D Control , Which is adopted which is adopted friendly and edited cutting programs easily
Function of 'SINUMERIK Dynamics. it can be read the programs in advance, and also enhanced the finish of parts' surface. Polent operation of machinery dynamics can be presented ultra-excellence in cutting 80 bits of NANO" Accuracy Operation, it is a real controlled-circuit for hi-accuracy completely.
1. Function of Shop Mail- in accordance with a single job, or small batches of producing needs, it shortens the time of editing programs.
2. Function of program GUIDE- On the basis of the demand of massive production, use the most flexible capability to enrich the production capacity
